How to use the combine harvester correctly

In the course of using the combine harvester, as the time goes by, the state of the technology deteriorates, and the working ability will gradually decrease, but the correct use and operation can extend its service life and improve its use reliability.

1. Test run. The new machine or the maintenance of the harvester must be commissioned.

1 The engine is commissioned. According to the maintenance and repair contents, it is decided to run at cold and hot temperatures and check whether the oil pressure gauge, oil temperature gauge, and water temperature gauge are normal, whether there is oil leakage, water seepage, or abnormal noise.

2 walk trial operation. According to the 1st, 2nd, 3rd, and reverse order, turn left and right respectively to check whether the steering mechanism and brake are sensitive and whether the clutch interlock mechanism is reliable.

3 Trial, threshing, separation, unloading, and other work organizations are commissioned to check the reliability and agility of the monitoring instruments.

2. Technical maintenance. Periodically clean, inspect, tighten, adjust, lubricate, add, and replace delicate parts of the combine harvester.

1 Clean the combine harvester, remove the hull on the machine, smash the stems and other attachments, lubricate all the friction parts in time, clean the outer chain and lubricate with the engine oil.

2 The inspection of the technical state of the engine includes whether the oil pressure, the oil temperature and the water temperature are normal, and whether the engine sounds fuel consumption is normal or not.

3 Inspection and adjustment of the header, including the speed and height of the reel, cutter stroke and cutting gap, whether the auger and the bottom clearance and the agitation speed meet the requirements.

4 threshing device inspection. It is mainly the drum rotation concave plate gap should meet the requirement, the rotation speed is higher, the gap is smaller, but cannot cause the grain to crush and the roller to block the phenomenon.

5 The inspection of the separation device and the cleaning device shall be checked after the drafter is tightened. The axial roller separation device is mainly to see whether the rotation of the roller is light, flexible and reliable.

6 other items checked. Whether there are cracks in the welding parts, whether all kinds of oil and water are clean and sufficient, whether the fasteners are firm, whether the movement of the rotating parts is flexible and reliable, and whether the operating device is flexible, accurate, and reliable, in particular, the hydraulic control mechanism must be used accurately.

3. Use and operate correctly. Operate according to the specification can reduce the failure to improve efficiency

1, some users in the maintenance of diesel fuel filter, the upper and lower sealing rubber gasket and oil cover is lost, so that the diesel does not filter through the filter core, but no resistance from the gap between the filter element and the filter cover Filter cavity, the diesel filter lost filter purification.

2. Some users reversed the positions of the trays and springs of the diesel filter and even discarded them so that the inlet and outlet ports of the diesel filter cover were open, and the diesel was not filtered and entered the injection pump directly.

3. When someone is maintaining the diesel filter, after opening the filter, he finds that the internal diesel is very clean. They do not know this is an illusion due to the filter core.

1 no load start the engine, low speed combined with clutch, plate movement control valve to decelerate the combine harvester, reduce the header to normal cutting height and increase the throttle engine up to the rated speed when the area harvests.

2 The harvester shall be stopped after 50 to 100 meters to check the quality of the work, and if necessary, necessary adjustments shall be made until the work quality meets the requirements and the work is put into normal operation.

3 Always use a large throttle to reduce the forward speed by reducing the throttle. The smaller the throttle, the slower the rhythm of the working mechanisms of the harvester and the threshing section of the harvester, which can reduce the quality of work or even clog the header or roller. Never shut down immediately after a large throttle operation.

4 Operation can be used to change speeds by manoeuvering valves and shifting gears.

5 Adjust the height of the header in time when the obstacle is crossed.

6 Normal temperature specifications, speed specifications and load specifications should be maintained during use.

4. Technical storage. The integrity of the combine harvester is ensured by its storage when it is idle.

1 Remove dust and dirt, open all windows of the unit, cover plates, and shrouds, and carefully remove grass clippings, broken stalks, and oil stains throughout the machine to make the unit clean.

2 Remove the chain, clean it with diesel oil and immersed in the oil for 20 minutes. Wrap it with paper and store it separately. Remove the tape, dry it after cleaning, and apply talcum powder. Keep it properly.

3 Replace the lubricant in each area and rotate it for several times without load.

4 Apply oil to prevent rust at work friction or paint stripping.

5 Brush the outside of the machine with water and dry with a small amount of lubricating oil with a rag.

6 After the machine is put into storage, lower the header on the pad, lift the jacks of the drive wheel bridge and the steering wheel bridge and pad the padding wood. The body is stable and the tires are off the ground, reducing the tire pressure to 1/3 of the standard air pressure. .

7 Relax the safety clutch spring and other springs.

8 During the storage period, the crankshaft is rotated 10 times at regular intervals, and the hydraulic distribution valve is toggled 15-20 times per month in each working position. To prevent the working surface of the cylinder piston from being rusted, the piston should be pushed to the bottom.

9 Engines and livestock batteries are kept in accordance with their respective technical storage regulations. The filter material is loose and the pores are too large. At this time, the filter paper does not function as a filter.

In short, the maintenance of diesel engine filter must be carried out according to the specified time and operation of the instruction manual. If the operating environment is bad, the maintenance cycle must be advanced. Disassembly, inspection and maintenance should be strictly in accordance with the procedures, must not think that all kinds of filter role is not, may or may not, otherwise the diesel engine can not maintain the technical condition intact, the function can not be normal play, and even will greatly reduce the diesel engine life span.
